Beyond SSH Tunnels: Secure K8s Access with WireGuard & Ansible

Even the most secure fortress can face an unexpected horde

Directly accessing Kubernetes services from outside the cluster can be a security and convenience nightmare. Tedious port-forward commands and exposed proxies are risky. This post details how I built a better solution: a secure, automated VPN tunnel into my cluster using WireGuard and Ansible, giving me direct, private network access to my K3s cluster.

The "Why": My Motivations

My journey began after hardening our servers per CIS Benchmarks, a standard security practice. This had an immediate side effect: my usual method of creating an SSH tunnel to use kubectl was disabled.

This was a blessing in disguise. Relying on any kind of forwarded port is a security risk, as it can potentially allow traceless horizontal attacks across your cluster if a developer's machine is compromised. I needed a better, more secure, and more robust way forward.

WireGuard was the obvious choice—it's the modern, fast, and secure de-facto standard for Kubernetes networking, using state-of-the-art cryptography. To make the entire setup repeatable and error-proof, I turned to Ansible for complete automation.

The "How": The Architecture and Setup

The architecture is simple: a WireGuard peer runs as a VPN server directly on our Kubernetes node (in this case, a VPS running K3s). Our client machines (laptops, etc.) connect to this peer, effectively joining the cluster's private network.

Prerequisites

• A running Kubernetes cluster (this guide uses K3s on a VPS).
• kubectl access to that cluster.
• Ansible installed on your control machine.
• A basic grasp of WireGuard concepts (Peers, Public/Private Keys).

The Core Components: Templates and Variables

Before diving into the playbook, let's look at the two key templates it uses.

1. The Server Configuration Template (wg0.conf.j2)

This is a Jinja2 template that Ansible uses to generate the server's final /etc/wireguard/wg0.conf file. Its power comes from the for loop, which dynamically adds a [Peer] block for every client defined in an Ansible variable.

[Interface]
Address = {{ wireguard_server_ip }}/24
ListenPort = {{ wireguard_server_port }}
PrivateKey = PLACEHOLDER

{% for client in wireguard_clients %}
[Peer]
# {{ client.name }}
PublicKey = {{ client.public_key }}
AllowedIPs = {{ client.ip }}/32
{% endfor %}

You would define the wireguard_clients variable in your Ansible inventory (e.g., in group_vars/all.yml) like this:

wireguard_clients:
  - name: my_laptop
    public_key: "PASTE_LAPTOP_PUBLIC_KEY_HERE"
    ip: "10.0.0.2"
  - name: my_phone
    public_key: "PASTE_PHONE_PUBLIC_KEY_HERE"
    ip: "10.0.0.3"

2. The Client Template (wg-client-template.conf)

This file lives on your local machine where you run Ansible. It's a generic client config with placeholders. Ansible will automatically fill in the server's PublicKey and Endpoint details.

[Interface]
PrivateKey = {{CLIENT_PRIVATE_KEY}}
Address = {{CLIENT_IP}}

[Peer]
PublicKey = {{PUBLIC_KEY}}
Endpoint = {{ENDPOINT}}
AllowedIPs = 10.0.0.0/24
PersistentKeepalive = 25

Step 1 & 2: The Server Setup & Ansible Automation

Our Ansible role, wireguard, automates the entire server configuration.

Here is the main task file:

# ansible/wireguard/tasks/main.yaml

- name: Ensure WireGuard tools are installed
  ansible.builtin.package:
    name: wireguard-tools
    state: present

- name: Ensure UFW is installed
  ansible.builtin.package:
    name: ufw
    state: present

- name: Create WireGuard config directory
  ansible.builtin.file:
    path: /etc/wireguard
    state: directory
    mode: '0700'

- name: Check for existing private key
  ansible.builtin.stat:
    path: /etc/wireguard/private_key
  register: private_key_stat

- name: Generate WireGuard keys on server
  ansible.builtin.shell:
    cmd: umask 077 && wg genkey > /etc/wireguard/private_key && wg pubkey < /etc/wireguard/private_key > /etc/wireguard/public_key
    creates: /etc/wireguard/private_key
  when: not private_key_stat.stat.exists

- name: Slurp WireGuard public key from remote server
  ansible.builtin.slurp:
    src: /etc/wireguard/public_key
  register: wireguard_public_key_b64

- name: Insert server public key into the client template
  ansible.builtin.lineinfile:
    path: "/project/wg-client-template.conf"
    regexp: '^PublicKey = .*$'
    line: "PublicKey = {{ wireguard_public_key_b64['content'] | b64decode }}"
    mode: '0644'
  delegate_to: localhost
  run_once: true
  become: no

- name: Insert server endpoint into the client template
  ansible.builtin.lineinfile:
    path: "/project/wg-client-template.conf"
    regexp: '^Endpoint = .*$'
    line: "Endpoint = {{ hostvars[inventory_hostname]['ansible_default_ipv4']['address'] }}:{{ wireguard_server_port }}"
    mode: '0644'
  delegate_to: localhost
  run_once: true
  become: no

- name: Configure WireGuard interface from template
  ansible.builtin.template:
    src: wg0.conf.j2
    dest: /etc/wireguard/wg0.conf
    owner: root
    group: root
    mode: '0600'

- name: Read private key from server file
  ansible.builtin.command: cat /etc/wireguard/private_key
  register: private_key_content
  changed_when: false
  check_mode: no
  no_log: true

- name: Insert private key into WireGuard config
  ansible.builtin.lineinfile:
    path: /etc/wireguard/wg0.conf
    line: "PrivateKey = {{ private_key_content.stdout }}"
    regexp: '^PrivateKey = PLACEHOLDER$'
    state: present
  no_log: true
  notify: restart wireguard

- name: Allow WireGuard port through UFW
  community.general.ufw:
    rule: allow
    port: "{{ wireguard_server_port }}"
    proto: udp
  notify: reload ufw

- name: Enable IP forwarding in UFW
  ansible.builtin.lineinfile:
    path: /etc/default/ufw
    regexp: '^DEFAULT_FORWARD_POLICY='
    line: 'DEFAULT_FORWARD_POLICY="ACCEPT"'
  notify: reload ufw

- name: Add UFW Postrouting rule for NAT
  ansible.builtin.blockinfile:
    path: /etc/ufw/before.rules
    block: |
      # START WIREGUARD RULES
      *nat
      :POSTROUTING ACCEPT [0:0]
      -A POSTROUTING -s {{ wireguard_server_ip }}/24 -o {{ ansible_default_ipv4.interface }} -j MASQUERADE
      COMMIT
      # END WIREGUARD RULES
    marker: "# {mark} ANSIBLE MANAGED BLOCK for WireGuard NAT"
  notify: reload ufw

- name: Allow K3s API port through UFW from WireGuard network
  community.general.ufw:
    rule: allow
    port: '6443'
    proto: tcp
    from_ip: "{{ wireguard_server_ip }}/24"
  notify: reload ufw

- name: Ensure WireGuard service is enabled and started
  ansible.builtin.service:
    name: wg-quick@wg0
    enabled: true
    state: started

Step 3: Configuring a New Client (The Full Workflow)

Here is the complete process to add a new client (e.g., your laptop) to the VPN.

1. Generate Client Keys: On your local machine, generate a new key pair.

   wg genkey | tee my_laptop_private.key | wg pubkey > my_laptop_public.key

   Keep the private key safe! You'll need it in a moment.

2. Update Ansible Variables: Copy the contents of my_laptop_public.key. Now, open your Ansible wireguard_clients variable list and add a new entry for your device.

   wireguard_clients:
     - name: my_laptop
       public_key: "COPIED_PUBLIC_KEY_GOES_HERE"
       ip: "10.0.0.2"
     # ... other clients

3. Run the Playbook: Execute your Ansible playbook. This will update the server's /etc/wireguard/wg0.conf file, adding your new laptop as a peer. It will also update your local wg-client-template.conf with the correct server info.

4. Create Your Final Client Config:

   • Open the now-updated wg-client-template.conf.
   • Copy the private key from my_laptop_private.key and paste it over the {{CLIENT_PRIVATE_KEY}} placeholder.
   • Replace {{CLIENT_IP}} with the same IP you used in the variable list (10.0.0.2).
   • Save this final file as wg0.conf on your laptop (e.g., in /etc/wireguard/).

5. Connect: Activate the tunnel using the WireGuard client on your OS (e.g., wg-quick up wg0). You're in!

The "Aha!" Moment: Using the Connection

Once the tunnel is active, you can access your cluster resources as if you were on the same local network. To confirm that kubectl can now see the cluster through the tunnel, you can run a simple command. Pointing kubectl directly to your server's WireGuard IP (e.g., 10.0.0.1, as defined in your wg0.conf.j2) should now work perfectly.

# Test kubectl access through the tunnel, replacing with your server's WG IP
kubectl --server [https://10.0.0.1:6443](https://10.0.0.1:6443) get all --all-namespaces

You can even access services by their internal ClusterIP. For instance, curl http://10.43.0.15 will just work.

More importantly, you can now permanently configure your ~/.kube/config file to point directly to the internal Kubernetes API server address (https://10.0.0.1:6443), removing any need for the API server to be exposed to the public internet.

Conclusion

By combining WireGuard and Ansible, we've created a robust, secure, and easy-to-manage way to access our Kubernetes resources. It's faster and more flexible than clunky SSH tunnels and more modern than older VPN solutions. The best part is that the entire process is automated, making it repeatable, reliable, and trivial to onboard new developers or devices.
